Engine Type |
4-stroke, air-cooled, SOHC, single-cylinder, carbureted (Keihin NCV24) |
Displacement |
144 cc |
Max Power |
~12 HP @ 8,000 rpm |
Max Torque |
~11.3 Nm @ 6,500 rpm |
Compression Ratio |
9.5:1 |
Ignition |
DC-CDI |
Starting System |
Electric and Kick start |
Transmission |
5-speed, return shift manual, with wet multi-disc clutch, chain drive |
Frame Type |
Perimeter steel frame |
Front Suspension |
35 mm inverted fork, ~185 mm travel |
Rear Suspension |
Uni-Trak mono-shock, adjustable preload, ~192 mm travel |
Front Brake |
240 mm petal disc, dual-piston caliper |
Rear Brake |
190 mm petal disc, single-piston caliper |
Front Tire |
2.75-21 |
Rear Tire |
4.10-18 |
Wheelbase |
~1,340–1,345 mm |
Dimensions (L × W × H) |
~2,050 mm × 830–950 mm × 1,155 mm |
Seat Height |
~865–870 mm |
Ground Clearance |
~295–300 mm |
Curb Weight |
~118–119 kg |
Fuel Tank Capacity |
~6.9 L |
Features |
Full LCD digital instrument, LED headlamp |
